100G-CFP-LR4-10KM (100% Brocade Compatible) ()
100GBase LR4, 10 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible.
100GBase LR4, 10 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible.
Please call for Pricing and Details.
Form Factor: CFP
Port Interface: 1 x 100GBase LC
Interface Details: 1 x 100GBase LR4
Data Rate: 100 Gbps
Wavelength: Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm
Distance: 10 Km (6.2 miles)
Temperature Range: Commercial 0°C to 70°C
Digital Diagnostics (DDM): Yes
Connection: Single-mode Fiber (SMF)
Hot Swappable: Yes
Dimensions: 0.54" x 3.23" x 5.70"
Compatibility: Brocade MLX Series
