CFP-100G

CFP-100G

The C form-factor pluggable (CFP) is a multi-source agreement to produce a common form-factor for the transmission of high-speed digital signals. The c stands for the Latin letter C used to express the number 100 (centum), since the standard was primarily developed for 100 Gigabit Ethernet systems.



The CFP transceiver is specified by a multi-source agreement (MSA) between competing manufacturers. The CFP was designed after the small form-factor pluggable transceiver (SFP) interface, but is significantly larger to support 100 Gbit/s. While the electrical connection of a CFP uses 10 x 10 Gbit/s lanes in each direction (RX, TX)[1] the optical connection can support both 10 x 10 Gbit/s and 4 x 25 Gbit/s variants of 100 Gbit/s interconnects (typically referred to as 100GBASE-SR10 in 100 meter MMF, 100GBASE-LR10 and 100GBASE-LR4 in 10 km SMF reach, and 100GBASE-ER10 and 100GBASE-ER4 in 40 km SMF reach respectively.)

View as Grid List
Sort by
Display per page

100GBASE-ER4 (100% Brocade Compatible)

100GBase ER, 40 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible.
$23,999.00 excl tax

100GBASE-LR4 (100% Brocade Compatible)

100GBase LR, 10 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible.
$24,999.00 excl tax

100GBASE-SR10 (100% Brocade Compatible)

100GBase SR-10, 125 meters, Ten 10.3 Gbps wavelengths: 840 nm - 860 nm CFP transceiver. 100% Brocade compatible.
$3,999.00 excl tax

100G-CFP-10X10-10KM (100% Brocade Compatible)

100GBase LR4, 10 Km, Ten 10.3 Gbps wavelengths: 1523 nm - 1595 nm CFP transceiver. 100% Brocade compatible.
Call for pricing

100G-CFP-10X10-2KM (100% Brocade Compatible)

100GBase LR4, 2 Km, Ten 10.3 Gbps wavelengths: 1523 nm - 1595 nm CFP transceiver. 100% Brocade compatible
Call for pricing

100G-CFP-ER4-40KM (100% Brocade Compatible)

100GBase ER, 40 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible
Call for pricing

100G-CFP-LR4-10KM (100% Brocade Compatible)

100GBase LR4, 10 Km, Four 25.8 Gbps wavelength lanes: 1294.53 nm - 1296.59 nm, 1299.02 nm - 1301.09 nm, 1303.54 nm - 1305.63 nm, 1308.09 nm - 1310.19 nm CFP transceiver. 100% Brocade compatible.
Call for pricing

100G-CFP-SR10 (100% Brocade Compatible)

100GBase SR-10, 125 meters, Ten 10.3 Gbps wavelengths: 840 nm - 860 nm CFP transceiver. 100% Brocade compatible.
Call for pricing
